foedus::thread::ThreadPoolPimpl Class Reference

Pimpl object of ThreadPool. More...

Detailed Description

Pimpl object of ThreadPool.

A private pimpl object for ThreadPool. Do not include this header from a client program unless you know what you are doing.

Definition at line 41 of file thread_pool_pimpl.hpp.

#include <thread_pool_pimpl.hpp>

Inheritance diagram for foedus::thread::ThreadPoolPimpl:

Collaboration diagram for foedus::thread::ThreadPoolPimpl:

Public Member Functions
	ThreadPoolPimpl ()=delete
	ThreadPoolPimpl (Engine *engine)
ErrorStack	initialize_once () override
ErrorStack	uninitialize_once () override
bool	impersonate (const proc::ProcName &proc_name, const void *task_input, uint64_t task_input_size, ImpersonateSession *session)
bool	impersonate_on_numa_node (ThreadGroupId node, const proc::ProcName &proc_name, const void *task_input, uint64_t task_input_size, ImpersonateSession *session)
bool	impersonate_on_numa_core (ThreadId core, const proc::ProcName &proc_name, const void *task_input, uint64_t task_input_size, ImpersonateSession *session)
ThreadGroupRef *	get_group (ThreadGroupId numa_node)
ThreadGroup *	get_local_group () const
ThreadRef *	get_thread (ThreadId id)
ThreadRef	get_thread_ref (ThreadId id) __attribute__((always_inline))
	For better performance, but for some reason this method causes an issue in MCS lock. More...
Public Member Functions inherited from foedus::DefaultInitializable
	DefaultInitializable ()
virtual	~DefaultInitializable ()
	DefaultInitializable (const DefaultInitializable &)=delete
DefaultInitializable &	operator= (const DefaultInitializable &)=delete
ErrorStack	initialize () override final
	Typical implementation of Initializable::initialize() that provides initialize-once semantics. More...
ErrorStack	uninitialize () override final
	Typical implementation of Initializable::uninitialize() that provides uninitialize-once semantics. More...
bool	is_initialized () const override final
	Returns whether the object has been already initialized or not. More...
Public Member Functions inherited from foedus::Initializable
virtual	~Initializable ()

Public Attributes
Engine *const	engine_
ThreadGroup *	local_group_
	Thread group of the local SOC engine. More...
std::vector< ThreadGroupRef >	groups_
	List of all thread groups, one for each NUMA node in this engine. More...

Friends
std::ostream &	operator<< (std::ostream &o, const ThreadPoolPimpl &v)

Constructor & Destructor Documentation

foedus::thread::ThreadPoolPimpl::ThreadPoolPimpl ( )

delete

foedus::thread::ThreadPoolPimpl::ThreadPoolPimpl ( Engine *  engine )

inlineexplicit

Definition at line 44 of file thread_pool_pimpl.hpp.

: engine_(engine), local_group_(nullptr) {}

Member Function Documentation

ThreadGroupRef* foedus::thread::ThreadPoolPimpl::get_group ( ThreadGroupId  numa_node )

inline

Definition at line 66 of file thread_pool_pimpl.hpp.

References groups_.

Referenced by foedus::thread::ThreadPool::get_group_ref(), and get_thread().

{ return &groups_[numa_node]; }

Here is the caller graph for this function:

ThreadGroup* foedus::thread::ThreadPoolPimpl::get_local_group ( ) const

inline

Definition at line 67 of file thread_pool_pimpl.hpp.

References local_group_.

Referenced by foedus::log::Logger::initialize_once().

{ return local_group_; }

Here is the caller graph for this function:

ThreadRef * foedus::thread::ThreadPoolPimpl::get_thread

(

ThreadId

id

)

Definition at line 74 of file thread_pool_pimpl.cpp.

References foedus::thread::decompose_numa_local_ordinal(), foedus::thread::decompose_numa_node(), get_group(), and foedus::thread::ThreadGroupRef::get_thread().

Referenced by foedus::thread::ThreadPool::get_thread_ref(), and impersonate_on_numa_core().

                                                  {
  return get_group(decompose_numa_node(id))->get_thread(decompose_numa_local_ordinal(id));
}

Here is the call graph for this function:

Here is the caller graph for this function:

ThreadRef foedus::thread::ThreadPoolPimpl::get_thread_ref ( ThreadId  id )

inline

For better performance, but for some reason this method causes an issue in MCS lock.

Definition at line 92 of file thread_pool_pimpl.hpp.

References foedus::thread::decompose_numa_local_ordinal(), foedus::thread::decompose_numa_node(), and groups_.

Referenced by foedus::thread::ThreadPimpl::get_thread_ref().

                                                            {
  ThreadGroupId numa_node = decompose_numa_node(id);
  ThreadLocalOrdinal core_ordinal = decompose_numa_local_ordinal(id);
  return groups_[numa_node].get_thread_ref(core_ordinal);
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool foedus::thread::ThreadPoolPimpl::impersonate	(	const proc::ProcName &	proc_name,
		const void *	task_input,
		uint64_t	task_input_size,
		ImpersonateSession *	session
	)

Definition at line 79 of file thread_pool_pimpl.cpp.

References engine_, foedus::Engine::get_options(), groups_, foedus::EngineOptions::thread_, foedus::thread::ThreadOptions::thread_count_per_group_, and foedus::thread::ThreadRef::try_impersonate().

Referenced by foedus::thread::ThreadPool::impersonate().

                               {
  uint16_t thread_per_group = engine_->get_options().thread_.thread_count_per_group_;
  for (ThreadGroupRef& group : groups_) {
    for (size_t j = 0; j < thread_per_group; ++j) {
      ThreadRef* thread = group.get_thread(j);
      if (thread->try_impersonate(proc_name, task_input, task_input_size, session)) {
        return true;
      }
    }
  }
  return false;
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool foedus::thread::ThreadPoolPimpl::impersonate_on_numa_core	(	ThreadId	core,
		const proc::ProcName &	proc_name,
		const void *	task_input,
		uint64_t	task_input_size,
		ImpersonateSession *	session
	)

Definition at line 111 of file thread_pool_pimpl.cpp.

References get_thread(), and foedus::thread::ThreadRef::try_impersonate().

Referenced by foedus::thread::ThreadPool::impersonate_on_numa_core().

                               {
  ThreadRef* thread = get_thread(core);
  return thread->try_impersonate(proc_name, task_input, task_input_size, session);
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool foedus::thread::ThreadPoolPimpl::impersonate_on_numa_node	(	ThreadGroupId	node,
		const proc::ProcName &	proc_name,
		const void *	task_input,
		uint64_t	task_input_size,
		ImpersonateSession *	session
	)

Definition at line 95 of file thread_pool_pimpl.cpp.

References engine_, foedus::Engine::get_options(), foedus::thread::ThreadGroupRef::get_thread(), groups_, foedus::EngineOptions::thread_, foedus::thread::ThreadOptions::thread_count_per_group_, and foedus::thread::ThreadRef::try_impersonate().

Referenced by foedus::thread::ThreadPool::impersonate_on_numa_node().

                               {
  uint16_t thread_per_group = engine_->get_options().thread_.thread_count_per_group_;
  ThreadGroupRef& group = groups_[node];
  for (size_t j = 0; j < thread_per_group; ++j) {
    ThreadRef* thread = group.get_thread(j);
    if (thread->try_impersonate(proc_name, task_input, task_input_size, session)) {
      return true;
    }
  }
  return false;
}

Here is the call graph for this function:

Here is the caller graph for this function:

ErrorStack foedus::thread::ThreadPoolPimpl::initialize_once ( )

overridevirtual

Implements foedus::DefaultInitializable.

Definition at line 40 of file thread_pool_pimpl.cpp.

References ASSERT_ND, CHECK_ERROR, engine_, ERROR_STACK, foedus::Engine::get_memory_manager(), foedus::Engine::get_options(), foedus::Engine::get_soc_id(), groups_, foedus::DefaultInitializable::initialize(), foedus::DefaultInitializable::is_initialized(), foedus::Engine::is_master(), foedus::kErrorCodeDepedentModuleUnavailableInit, foedus::kRetOk, local_group_, and foedus::EngineOptions::thread_.

                                            {
  if (!engine_->get_memory_manager()->is_initialized()) {
    return ERROR_STACK(kErrorCodeDepedentModuleUnavailableInit);
  }
  ASSERT_ND(groups_.empty());
  const ThreadOptions &options = engine_->get_options().thread_;
  for (ThreadGroupId group_id = 0; group_id < options.group_count_; ++group_id) {
    groups_.emplace_back(ThreadGroupRef(engine_, group_id));
  }

  if (!engine_->is_master()) {
    // initialize local thread group object
    soc::SocId node = engine_->get_soc_id();
    local_group_ = new ThreadGroup(engine_, node);
    CHECK_ERROR(local_group_->initialize());
  }
  return kRetOk;
}

Here is the call graph for this function:

ErrorStack foedus::thread::ThreadPoolPimpl::uninitialize_once ( )

overridevirtual

Implements foedus::DefaultInitializable.

Definition at line 59 of file thread_pool_pimpl.cpp.

References ASSERT_ND, foedus::ErrorStackBatch::emprace_back(), engine_, ERROR_STACK, foedus::Engine::get_memory_manager(), groups_, foedus::DefaultInitializable::is_initialized(), foedus::Engine::is_master(), foedus::kErrorCodeDepedentModuleUnavailableUninit, local_group_, SUMMARIZE_ERROR_BATCH, and foedus::DefaultInitializable::uninitialize().

                                              {
  ErrorStackBatch batch;
  if (!engine_->get_memory_manager()->is_initialized()) {
    batch.emprace_back(ERROR_STACK(kErrorCodeDepedentModuleUnavailableUninit));
  }

  groups_.clear();
  if (local_group_) {
    ASSERT_ND(!engine_->is_master());
    batch.emprace_back(local_group_->uninitialize());
    delete local_group_;
    local_group_ = nullptr;
  }
  return SUMMARIZE_ERROR_BATCH(batch);
}

Here is the call graph for this function:

Friends And Related Function Documentation

std::ostream& operator<< ( std::ostream &  o, const ThreadPoolPimpl &  v  )

friend

Definition at line 121 of file thread_pool_pimpl.cpp.

                                                                {
  o << "<ThreadPool>";
  o << "<groups>";
  for (const ThreadGroupRef& group : v.groups_) {
    o << group;
  }
  o << "</groups>";
  o << "</ThreadPool>";
  return o;
}

Member Data Documentation

Engine* const foedus::thread::ThreadPoolPimpl::engine_

Definition at line 77 of file thread_pool_pimpl.hpp.

Referenced by impersonate(), impersonate_on_numa_node(), initialize_once(), and uninitialize_once().

std::vector<ThreadGroupRef> foedus::thread::ThreadPoolPimpl::groups_

List of all thread groups, one for each NUMA node in this engine.

Index is ThreadGroupId.

Definition at line 89 of file thread_pool_pimpl.hpp.

Referenced by get_group(), get_thread_ref(), impersonate(), impersonate_on_numa_node(), initialize_once(), foedus::thread::operator<<(), and uninitialize_once().

ThreadGroup* foedus::thread::ThreadPoolPimpl::local_group_

Thread group of the local SOC engine.

If this is a master engine, null.

Definition at line 83 of file thread_pool_pimpl.hpp.

Referenced by get_local_group(), initialize_once(), and uninitialize_once().

---

The documentation for this class was generated from the following files:

• /home/shino/foedus_code/foedus-core/include/foedus/thread/thread_pool_pimpl.hpp
• /home/shino/foedus_code/foedus-core/src/foedus/thread/thread_pool_pimpl.cpp
