Array Storage, a dense and regular array. More...

Detailed Description

Array Storage, a dense and regular array.

Basic Structure

Our array-storage is an extremely simple data structure at the cost of limited applicability (fix-sized, regular, dense arrays). The page layout has little per-page information that is dynamic, meaning that most data never changes after the array storage is created. Further, as everything is pre-allocated, no phantoms, no insertion/splits, nor anything complex. Thus, little synchronization hassles.

Supported Operations

Array storage allows very few data operations.

Reads a record or a range of records.
Overwrites a record.
Reads a range of records in batched fashion. (Not implemented so far, just loop over it. This might be useful for a big array of really small records to avoid function call overheads.)

In other words, the following operations are NOT supported.

Inserts or Deletes a record because all records always exist in an array storage (dense array). Client programs can achieve the same thing by storing one-bit in payload as a deletion-flag and overwrites it.
Resize individual records or the entire array. All records are fix-sized and pre-allocated when the array storage is initialized.

If these limitations do not cause an issue, array storage is a best choice as it's extremely efficient and scalable thanks to the simplicity.

Page Hierarchy

Despite the name of this storage type, we do have a page hierarchy, which is required to handle switches between volatile/snapshot pages. Hence, a more precise description of this storage type is a fix-sized pre-allocated tree that has only integer-keys from 0 to array_size-1.

All data (payload) are stored in leaf pages and interior pages contain only pointers to its children. There is only one root page per array, which may or may not be a leaf page. Just like B-trees in many sense.

Page Layout

Header and Data

Fix-Sized HEADER (kHeaderSize bytes)	DATA

Interior Node Data

InteriorRecord	InteriorRecord	...

See foedus::storage::array::ArrayPage::InteriorRecord.

Leaf Node Data

Record	Padding	Record	Padding	...

We simply puts foedus::storage::Record contiguously, but with a padding (0-7 bytes). to make sure Record are 8-byte aligned because we do atomic operations on Record's owner_id_.

Concurrency Control

We do a bit special concurrency control for this storage type. Because everything is pre-allocated and no split/physical-delete/merge whatsoever, we can do the ModCount concurrency control per Record, not per page. We store ModCount for each record, instead stores no ModCount in page header. Thus, individual transactions that update records in same page have no contention except they update the exact same record. We even don't track node-set; only record-set is checked at commit.

This simplifies and increases concurrency for most data accesses, but we have to be careful when the page eviction thread drops the volatile page. We need to know the largest Epoch of records in the page at the point, but concurrent transactions might be modifying records at the same time. Thus, we do two-path optimistic concurrency control similar to our commit protocol for Masstree Storage.

The eviction thread takes a look at all Epoch in the page, remembering the largest one.
Fence
Then, it puts a mark on the pointer from the parent page to the evicted page to announce that the volatile page is about to be evicted.
Fence
Finally, it takes a look at all Epoch in the page again and completes the eviction only if it sees the same largest Epoch. If not, gives up (because the volatile page is now newer, no chance to drop it with the latest snapshot version).

References

[SCIDB] Cudre-Mauroux, P. and Kimura, H. and Lim, K.-T. and Rogers, J. and Simakov, R. and Soroush, E. and Velikhov, P. and Wang, D. L. and Balazinska, M. and Becla, J. and DeWitt, D. and Heath, B. and Maier, D. and Madden, S. and Patel, J. and Stonebraker, M. and Zdonik, S. "A demonstration of SciDB: a science-oriented DBMS.", VLDB, 2009.

Collaboration diagram for Array Storage:

Files
file	array_id.hpp
	Definitions of IDs in this package and a few related constant values.

file	array_log_types.hpp
	Declares all log types used in this storage type.

file	fwd.hpp
	Forward declarations of classes in array storage package.

Classes
class	foedus::storage::array::ArrayComposer
	Composer for an array storage. More...

struct	foedus::storage::array::ArrayRange
	Represents an offset range in an array storage. More...

struct	foedus::storage::array::ArrayCreateLogType
	Log type of CREATE ARRAY STORAGE operation. More...

struct	foedus::storage::array::ArrayCommonUpdateLogType
	A base class for ArrayOverwriteLogType/ArrayIncrementLogType. More...

struct	foedus::storage::array::ArrayOverwriteLogType
	Log type of array-storage's overwrite operation. More...

struct	foedus::storage::array::ArrayIncrementLogType
	Log type of array-storage's increment operation. More...

struct	foedus::storage::array::ArrayMetadata
	Metadata of an array storage. More...

union	foedus::storage::array::ArrayPage::Data
	Data union for either leaf (dynamic size) or interior (fixed size). More...

class	foedus::storage::array::ArrayPage
	Represents one data page in Array Storage. More...

class	foedus::storage::array::ArrayPartitioner
	Partitioner for an array storage. More...

union	foedus::storage::array::LookupRoute
	Compactly represents the route to reach the given offset. More...

class	foedus::storage::array::LookupRouteFinder
	Packages logic and required properties to calculate LookupRoute in array storage from offset. More...

class	foedus::storage::array::ArrayStorage
	Represents a key-value store based on a dense and regular array. More...

class	foedus::storage::array::ArrayStoragePimpl
	Pimpl object of ArrayStorage. More...

struct	foedus::storage::sequential::SequentialAppendLogType
	Log type of sequential-storage's append operation. More...

Typedefs
typedef uint64_t	foedus::storage::array::ArrayOffset
	The only key type in array storage. More...

Functions
void	foedus::storage::array::array_volatile_page_init (const VolatilePageInitArguments &args)
	volatile page initialize callback for ArrayPage. More...

void	foedus::storage::hash::hash_intermediate_volatile_page_init (const VolatilePageInitArguments &args)
	volatile page initialize callback for HashIntermediatePage. More...

void	foedus::storage::hash::hash_data_volatile_page_init (const VolatilePageInitArguments &args)
	volatile page initialize callback for HashDataPage. More...

Variables
const ArrayOffset	foedus::storage::array::kMaxArrayOffset = (1ULL << 48) - 1ULL
	The maximum value allowed for ArrayOffset. More...

const uint16_t	foedus::storage::array::kHeaderSize = 64
	Byte size of header in each page of array storage. More...

const uint16_t	foedus::storage::array::kDataSize = foedus::storage::kPageSize - kHeaderSize
	Byte size of data region in each page of array storage. More...

const uint16_t	foedus::storage::array::kInteriorSize = 16
	Byte size of an entry in interior page of array storage. More...

const uint16_t	foedus::storage::array::kInteriorFanout = (foedus::storage::kPageSize - kHeaderSize) / kInteriorSize
	Max number of entries in an interior page of array storage. More...

const uint8_t	foedus::storage::array::kMaxLevels = 8
	Code in array storage assumes this number as the maximum number of levels. More...

const uint16_t	foedus::storage::kRecordOverhead = sizeof(xct::RwLockableXctId)
	Byte size of system-managed region per each record. More...

Class Documentation

union foedus::storage::array::ArrayPage::Data

Data union for either leaf (dynamic size) or interior (fixed size).

Definition at line 51 of file array_page_impl.hpp.

Collaboration diagram for foedus::storage::array::ArrayPage::Data:

[legend]

Class Members
DualPagePointer	interior_data[kInteriorFanout]
char	leaf_data[kInteriorFanout *sizeof(DualPagePointer)]

Typedef Documentation

typedef uint64_t foedus::storage::array::ArrayOffset

The only key type in array storage.

The key in array storage is offset, or an integer starting from zero. This means we don't support multi-dimensional, dynamic, sparse, nor any other fancy arrays. However, those arrays can be provided by the relational layer based on this array storage. The offset-conversion is fairly straightforward.

Note: Although it is an 8-byte integer, The valid value range of ArrayOffset is 0 to 2^48 - 1. Creating an array of size 2^48 or more will fail. This won't cause any issue in reality yet allows the implementation to pack more information.

See also: kMaxArrayOffset

Definition at line 48 of file array_id.hpp.

Function Documentation

void foedus::storage::array::array_volatile_page_init ( const VolatilePageInitArguments & args )

volatile page initialize callback for ArrayPage.

See also: foedus::storage::VolatilePageInit

Definition at line 78 of file array_page_impl.cpp.

Referenced by foedus::storage::array::ArrayStoragePimpl::follow_pointer(), foedus::storage::array::ArrayStoragePimpl::follow_pointers_for_read_batch(), and foedus::storage::array::ArrayStoragePimpl::follow_pointers_for_write_batch().

                                                                      {
   ASSERT_ND(args.parent_);
   ASSERT_ND(args.page_);
   ASSERT_ND(args.index_in_parent_ < kInteriorFanout);
   const ArrayPage* parent = reinterpret_cast<const ArrayPage*>(args.parent_);
   ArrayPage* page = reinterpret_cast<ArrayPage*>(args.page_);

   Engine* engine = args.context_->get_engine();
   StorageId storage_id = parent->get_storage_id();
   ArrayStorage storage(engine, storage_id);
   ASSERT_ND(storage.exists());
   const ArrayStorageControlBlock* cb = storage.get_control_block();

   ArrayRange parent_range = parent->get_array_range();
   uint8_t parent_level = parent->get_level();
   ASSERT_ND(parent_level > 0);
   ASSERT_ND(parent_range.end_ - parent_range.begin_ == cb->intervals_[parent_level]
     || parent_range.end_ == storage.get_array_size());

   uint8_t child_level = parent_level - 1U;
   uint64_t interval = cb->intervals_[child_level];
   ASSERT_ND(interval > 0);
   ArrayRange child_range;
   child_range.begin_ = parent_range.begin_ + args.index_in_parent_ * interval;
   child_range.end_ = child_range.begin_ + interval;
   if (child_range.end_ > storage.get_array_size()) {
     child_range.end_ = storage.get_array_size();
   }
   ASSERT_ND(child_range.end_ > 0);

   // Because this is a new page, records in it are in the earliest epoch of the system
   Epoch initial_epoch = engine->get_savepoint_manager()->get_initial_current_epoch();
   page->initialize_volatile_page(
     initial_epoch,
     storage_id,
     args.page_id,
     storage.get_payload_size(),
     child_level,
     child_range);
 }

Here is the call graph for this function:

Here is the caller graph for this function:

void foedus::storage::hash::hash_data_volatile_page_init ( const VolatilePageInitArguments & args )

volatile page initialize callback for HashDataPage.

See also: foedus::storage::VolatilePageInit

Definition at line 232 of file hash_page_impl.cpp.

Referenced by foedus::storage::hash::HashStoragePimpl::follow_page_bin_head().

                                                                          {
   ASSERT_ND(args.parent_);
   ASSERT_ND(args.page_);
   StorageId storage_id = args.parent_->get_header().storage_id_;
   HashDataPage* page = reinterpret_cast<HashDataPage*>(args.page_);
   PageType parent_type = args.parent_->get_header().get_page_type();
   uint64_t bin;
   if (parent_type == kHashIntermediatePageType) {
     const HashIntermediatePage* parent
       = reinterpret_cast<const HashIntermediatePage*>(args.parent_);

     ASSERT_ND(args.index_in_parent_ < kHashIntermediatePageFanout);
     ASSERT_ND(parent->get_level() == 0);
     ASSERT_ND(parent->get_bin_range().length() == kHashIntermediatePageFanout);
     bin = parent->get_bin_range().begin_ + args.index_in_parent_;
   } else {
     ASSERT_ND(parent_type == kHashDataPageType);
     ASSERT_ND(args.index_in_parent_ == 0);
     const HashDataPage* parent = reinterpret_cast<const HashDataPage*>(args.parent_);
     bin = parent->get_bin();
   }
   HashStorage storage(args.context_->get_engine(), storage_id);
   uint8_t bin_shifts = storage.get_bin_shifts();
   page->initialize_volatile_page(storage_id, args.page_id, args.parent_, bin, bin_shifts);
 }

Here is the call graph for this function:

Here is the caller graph for this function:

void foedus::storage::hash::hash_intermediate_volatile_page_init ( const VolatilePageInitArguments & args )

volatile page initialize callback for HashIntermediatePage.

See also: foedus::storage::VolatilePageInit

Definition at line 213 of file hash_page_impl.cpp.

References ASSERT_ND, foedus::storage::Page::get_header(), foedus::storage::PageHeader::get_page_type(), foedus::storage::VolatilePageInitArguments::index_in_parent_, foedus::storage::hash::HashIntermediatePage::initialize_volatile_page(), foedus::storage::hash::kHashIntermediatePageFanout, foedus::storage::kHashIntermediatePageType, foedus::storage::hash::kHashMaxBins, foedus::storage::VolatilePageInitArguments::page_, foedus::storage::VolatilePageInitArguments::page_id, foedus::storage::VolatilePageInitArguments::parent_, and foedus::storage::PageHeader::storage_id_.

Referenced by foedus::storage::hash::HashStoragePimpl::follow_page().

                                                                                  {
   ASSERT_ND(args.parent_);  // because this is always called for non-root pages.
   ASSERT_ND(args.page_);
   ASSERT_ND(args.index_in_parent_ < kHashIntermediatePageFanout);
   StorageId storage_id = args.parent_->get_header().storage_id_;
   HashIntermediatePage* page = reinterpret_cast<HashIntermediatePage*>(args.page_);

   ASSERT_ND(args.parent_->get_header().get_page_type() == kHashIntermediatePageType);
   const HashIntermediatePage* parent = reinterpret_cast<const HashIntermediatePage*>(args.parent_);

   ASSERT_ND(parent->get_level() > 0);
   parent->assert_range();
   HashBin interval = kHashMaxBins[parent->get_level()];
   HashBin parent_begin = parent->get_bin_range().begin_;
   HashBin begin = parent_begin + args.index_in_parent_ * interval;
   uint8_t level = parent->get_level() - 1U;
   page->initialize_volatile_page(storage_id, args.page_id, parent, level, begin);
 }

Here is the call graph for this function:

Here is the caller graph for this function:

Variable Documentation

const uint16_t foedus::storage::array::kDataSize = foedus::storage::kPageSize - kHeaderSize

Byte size of data region in each page of array storage.

Definition at line 100 of file array_id.hpp.

Referenced by foedus::storage::array::ArrayOverwriteLogType::apply_record(), foedus::storage::array::calculate_levels(), foedus::storage::array::ArrayStoragePimpl::calculate_offset_intervals(), foedus::storage::array::ArrayStoragePimpl::calculate_required_pages(), foedus::storage::array::ArrayPage::get_leaf_record(), foedus::storage::array::ArrayPage::get_leaf_record_count(), and foedus::storage::array::to_records_in_leaf().

const uint16_t foedus::storage::array::kHeaderSize = 64

Byte size of header in each page of array storage.

Definition at line 95 of file array_id.hpp.

const uint16_t foedus::storage::array::kInteriorFanout = (foedus::storage::kPageSize - kHeaderSize) / kInteriorSize

Max number of entries in an interior page of array storage.

Definition at line 110 of file array_id.hpp.

const uint16_t foedus::storage::array::kInteriorSize = 16

Byte size of an entry in interior page of array storage.

Definition at line 105 of file array_id.hpp.

const ArrayOffset foedus::storage::array::kMaxArrayOffset = (1ULL << 48) - 1ULL

The maximum value allowed for ArrayOffset.

Definition at line 54 of file array_id.hpp.

Referenced by foedus::storage::array::ArrayStoragePimpl::load_empty(), and foedus::storage::array::SortEntry::set().

const uint8_t foedus::storage::array::kMaxLevels = 8

Code in array storage assumes this number as the maximum number of levels.

Interior page always has a big fanout close to 256, so 8 levels are more than enough.

Definition at line 118 of file array_id.hpp.

Referenced by foedus::storage::array::ArrayComposer::compose().

const uint16_t foedus::storage::kRecordOverhead = sizeof(xct::RwLockableXctId)

Byte size of system-managed region per each record.

Definition at line 56 of file record.hpp.

Detailed Description

Basic Structure

Supported Operations

Page Hierarchy

Page Layout

Concurrency Control

References

Files

Classes

Typedefs

Functions

Variables

Class Documentation

Typedef Documentation

Function Documentation

Variable Documentation
